The personal tracker ADM50 is a portable device with built-in antennas, a battery and several modes of operation. The device can be used for monitoring of cargo containers, control of transport, observation of people, animals and other objects.
The tracker registers the location, speed and direction of the object's by signals from GLONASS/GSP system.
All events and conditions registered by the terminal are stored in a non-volatile memory. The accumulated data is transmitted through GSM 850/900/1800/1900 network of cell communications operator with the use of GPRS packet data transmission technology to a dedicated server from which it can be obtained via the Internet for further analysis and processing at the dispatcher console.
GLONASS/GPS of the receiver | |
Chipset | МТ3333 (MediaTek) |
Frequency coverage | GLONASS - L1 (CТ- code), GPS - L1 (С/А code) |
Sensitivity at cold start/at tracking | -148 dBm/-163dBm |
Number of tracking channels/lock-in channels | 33/99 |
Positioning accuracy, 95% of time, at least | 3 m |
Communications standard | GSM 850/900/1800/1900, GPRS Multi-slot Class 12 |
GSM transmitter power | 2 W |
SIM card | 1 |
Accelerometer | digital, three-axis |
Battery | Li-Ion, 3000mA |
Number of route records to store | 100 000 |
PC communication interface | USB |
Operating temperature in the discharge mode of the battery | -20..+60°С |
Operating temperature in battery charging mode | 0..+45°С |
Maximum current consumption current | in battery charging mode to 1 А |
Charger voltage | 5V |
Dimensions | 89х56х25mm |
Weight | maximum 125 g |
